Product Specification

: Home Appliances  >  Cooling and Heating  >  Air Conditioners
Dimension (Length x Width x Height)
: 30.00 x 30.00 x 30.00
: 40.00
Manufacturing Country
: Malaysia
Warranty Type
: No Warranty
Warranty Value
: -
Warranty Description
: -
Ship From
: Johor

Product Description

Horse Power: 2.5HP

Cooling Capacity: 22,500 (3,820-24,200) Btu/h

Comfort Technology: AEROWINGS, nanoe-G, Inverter, ECONAVI, R32 Refrigerant



Model: Indoor (50Hz): CS-U24VKH-1

Model: Outdoor (50Hz): CU-U24VKH-1

Refrigerant Type: R32

Cooling Capacity: (min-maX) kW: 6.60 (1.12-7.10)

Cooling Capacity: (min-maX)Btu/h: 22,500 (3,820-24,200)

EER: (min-maX) Btu/hW: 12.23 (11.94 -12.10)

EER: (min-maX) W/W: 3.59 (3.50-3.55)

CSPF: Wh/Wh: 5.81

Electrical Data: Voltage (V): 230

Electrical Data: Running Current (A): 8.3

Electrical Data: Power Input (W): 1,840 (320-2,000)

Moisture Removal: L/h: 3.7

Moisture Removal: Pt/h: 7.8

Air Circulation: Indoor m3/min (ft3/min): 20.2 (715)

Air Circulation: Outdoor m3/min (ft3/min): 36.0 (1,270)

Noise Level: Indoor (H/L/Q-Lo) (dB-A): 45/34/31

Noise Level: Outdoor (H / L) (dB-A): 52

Dimensions: Height (mm): 302 (619)

Dimensions: Height (inch): 11-29/32 (24-3/8)

Dimensions: Width (mm): 1,120 (824)

Dimensions: Width (inch): 44-1/8 (32-15/32)

Dimensions: Depth (mm): 241 (299)

Dimensions: Depth (inch): 9-1/2 (11-25/32)

Net Weight: Indoor kg (lb): 12 (26)

Net Weight: Outdoor kg (lb): 35 (77)

Refrigerant Pipe Diameter: Liquid Side (mm):  6.35

Refrigerant Pipe Diameter: Liquid Side (inch): 1/4

Refrigerant Pipe Diameter: Gas Side (mm):  15.88

Refrigerant Pipe Diameter: Gas Side (inch): 5/8

Pipe EXtension: Chargeless Pipe Length (m): 10

Pipe EXtension: MaXimum Pipe Length (m): 30

Pipe EXtension: MaXimum Elevation Length (m): 20

Pipe EXtension: Additional Refrigerant Gas* (g/m): 25

Power Supply: Indoor

Cleaner Air: nanoeTMX: No

Cleaner Air: nanoe-G: Yes

Cleaner Air: Anti-Dust Coating: No

Cleaner Air: Dust Sensor: No

Cleaner Air: Odour-Removing Function: Yes

Cleaner Air: Removable, Washable Panel: Yes

Comfort: Radiant Cooling: No

Comfort: iAUTO-X: Yes

Comfort: ECONAVI: Yes

Comfort: Temperature Wave: Yes

Comfort: SLEEP: Yes

Comfort: Inverter Control: Yes

Comfort: iAUTO: No

Comfort: Quiet Mode: Yes

Comfort: Soft Dry Operation Mode: Yes

Comfort: Personal Airflow Creation: Yes

Comfort: Airflow Direction Control (Up Down): No

Comfort: Manual Horizontal Airflow Direction Control: No

Convenience: 24-Hour Dual ON OFF Real Setting Timer: Yes

Convenience: 24-Hour ON OFF Real Setting Timer: No

Convenience: LCD Wireless Remote Control: Yes

Convenience: Wireless LAN Remote Control For Internet Connection: Yes (Optional)

Convenience: Wired Remote Control: Yes (Optional)

Reliability: Random Auto Restart (32 Restart Patterns): Yes

Reliability: Blue Fin Condenser: Yes

Reliability: Long Piping (Numbers indicate the maXimum pipe length): 30m

Reliability: Top-Panel Maintenance Access: Yes

Reliability: Self-Diagnostic Function Yes

NOTE: Caution For CS-U10/U13/U18/U24VKH/U28VKH-1 (Important) Please do not use copper pipes that are less than 0.6mm in thickness.

* When pipes are not eXtended from the standard pipe length, the requ
